ADW1209TW

Image is for reference, please contact us to get the real picture

Manufacturer Part
ADW1209TW
Manufacturer
Panasonic
Description
RELAY GENERAL PURPOSE SPST 8A 9V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
100
Datasheets
-

ADW1209TW Specifications

  • Series:DW
  • Package:Tray
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:9VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):8 A
  • Switching Voltage:250VAC - Max
  • Coil Current:44.4 mA
  • Coil Type:Latching, Dual Coil
  • Features:IEC Compliant
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Flux Protection
  • Coil Insulation:Class F
  • Must Operate Voltage:7.2 VDC
  • Must Release Voltage:-
  • Operate Time:15 ms
  • Release Time:15 ms
  • Operating Temperature:-40°C ~ 85°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
