JS1F-12V-F

Image is for reference, please contact us to get the real picture

Manufacturer Part
JS1F-12V-F
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPDT 10A 12V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
1502200
Datasheets
-

JS1F-12V-F Specifications

  • Series:JS
  • Package:Bulk
  • Part Status:Not For New Designs
  • Mounting Type:Through Hole
  • Coil Voltage:12VDC
  • Contact Form:SPDT (1 Form C)
  • Contact Rating (Current):10 A
  • Switching Voltage:250VAC, 100VDC - Max
  • Coil Current:30 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Flux Protection
  • Coil Insulation:-
  • Must Operate Voltage:8.4 VDC
  • Must Release Voltage:1.2 VDC
  • Operate Time:10 ms
  • Release Time:10 ms
  • Operating Temperature:-40°C ~ 70°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
