L6562AD technical parameters detailed explanation and pin diagram

L6562AD is an AC-DC controller and voltage regulator launched by STMicroelectronics (ST). TOPCHIP ELECTRONICS, a supplier of a full range of IC electronic components under STMicroelectronics, will provide you with detailed explanations of L6562AD parameters, functional features, applications, attached pin diagrams, and schematics.

Detailed explanation of L6562AD technical parameters

Brand: STMicroelectronics

Product Family: Power Management ICs - AC-DC Controllers and Regulators

Packaging: pipe fittings

Part status: active

Mode: Intermittent (jump)

Current-start: 30μA

Voltage-power supply: 10.5V ~ 22.5V

Working temperature: -25°C ~ 125°C

Standard packaging: 1 piece/tube

Package: SO-8

L6562AD features

1. High-precision voltage and current control can achieve stable output voltage and current;

2. Built-in overload and short-circuit protection functions to ensure the safety of circuits and equipment;

3. Using PWM control technology, it has the characteristics of high efficiency and low power consumption;

4. Integrate a variety of protection functions, such as overvoltage, undervoltage, overtemperature, etc., to improve the reliability of the system.

L6562AD application fields

1. Power adapter and charger;

2. LED lighting system;

3. Power management systems for industrial and communication equipment;

4. Power control of household appliances and consumer electronics.

L6562AD pin diagram

L6562AD schematic diagram
