DG4157DN-T1-E4 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:1
• On-State Resistance (Max):1.2Ohm
• Channel-to-Channel Matching (ΔRon):120mOhm (Max)
• Voltage - Supply, Single (V+):1.65V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):37ns, 23ns
• -3db Bandwidth:117MHz
• Charge Injection:50pC
• Channel Capacitance (CS(off), CD(off)):20pF
• Current - Leakage (IS(off)) (Max):2nA
• Crosstalk:-63dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:6-UFDFN
• Supplier Device Package:6-miniQFN
