DG2518DN-T1-E4 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):4Ohm
• Channel-to-Channel Matching (ΔRon):100mOhm
• Voltage - Supply, Single (V+):1.8V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):25ns, 20ns
• -3db Bandwidth:242MHz
• Charge Injection:2pC
• Channel Capacitance (CS(off), CD(off)):8pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-73dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:10-VFDFN Exposed Pad
• Supplier Device Package:10-DFN (3x3)
