DG613AEQ-T1-E3 Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Switch Circuit:SPST - NO/NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):115Ohm
• Channel-to-Channel Matching (ΔRon):700mOhm
• Voltage - Supply, Single (V+):2.7V ~ 12V
• Voltage - Supply, Dual (V±):±2.7V ~ 5V
• Switch Time (Ton, Toff) (Max):55ns, 35ns
• -3db Bandwidth:720MHz
• Charge Injection:1pC
• Channel Capacitance (CS(off), CD(off)):2pF, 3pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-90dB @ 10MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-TSSOP (0.173", 4.40mm Width)
• Supplier Device Package:16-TSSOP
