NLAS4501DTT1 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:1
• On-State Resistance (Max):25Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):2V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):9ns, 10ns
• -3db Bandwidth:220MHz
• Charge Injection:3pC
• Channel Capacitance (CS(off), CD(off)):10pF, 10pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-
• Operating Temperature:-55°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:SOT-23-5 Thin, TSOT-23-5
• Supplier Device Package:5-TSOP
