JN2AW05FH1

Image is for reference, please contact us to get the real picture

Manufacturer Part
JN2AW05FH1
Manufacturer
JAE Electronics
Description
CONN RCPT FMALE 5P SOLDER CUP
Category
Connectors, Interconnects
Family
Circular Connectors
Series
-
In Stock
0
Datasheets
-

JN2AW05FH1 Specifications

  • Series:JN2W
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Receptacle, Female Sockets
  • Number of Positions:5 (4 Power + PE)
  • Shell Size - Insert:W
  • Shell Size, MIL:-
  • Mounting Type:Panel Mount
  • Mounting Feature:Flange
  • Termination:Solder Cup
  • Fastening Type:Push-Twist
  • Orientation:N (Normal)
  • Shell Material:Zinc Alloy
  • Shell Finish:Zinc
  • Contact Finish - Mating:Silver
  • Color:Black
  • Ingress Protection:IP67 - Dust Tight, Waterproof
  • Material Flammability Rating:-
  • Features:Ground Lug
  • Shielding:-
  • Current Rating (Amps):13A
  • Voltage Rating:400VAC
  • Cable Opening:-
  • Operating Temperature:-20°C ~ 100°C
