153222-2020-RB-WD

Image is for reference, please contact us to get the real picture

Manufacturer Part
153222-2020-RB-WD
Manufacturer
3M
Description
CONN RCPT 22POS 0.079 GOLD SMD
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
0
Datasheets
-

153222-2020-RB-WD Specifications

  • Series:1532
  • Package:Tape & Reel (TR)
  • Part Status:Obsolete
  • Connector Type:Receptacle, Bottom or Top Entry
  • Contact Type:Female Socket
  • Style:Board to Board or Cable
  • Number of Positions:22
  • Number of Positions Loaded:All
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.079" (2.00mm)
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Insulation Color:Black
  • Insulation Height:0.129" (3.28mm)
  • Contact Length - Post:-
  • Operating Temperature:-55°C ~ 105°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:-
  • Ingress Protection:-
  • Features:Board Guide, Pick and Place
  • Current Rating (Amps):1A
  • Voltage Rating:500VDC
