M50-4303945

Image is for reference, please contact us to get the real picture

Manufacturer Part
M50-4303945
Manufacturer
Harwin
Description
CONN RCPT 78POS 0.05 GOLD SMD
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
0
Datasheets
-

M50-4303945 Specifications

  • Series:Archer M50
  • Package:Tube
  • Part Status:Obsolete
  • Connector Type:Receptacle
  • Contact Type:Female Socket
  • Style:Board to Board
  • Number of Positions:78
  • Number of Positions Loaded:All
  • Pitch - Mating:0.050" (1.27mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.050" (1.27mm)
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:-
  • Insulation Color:Black
  • Insulation Height:0.181" (4.60mm)
  • Contact Length - Post:-
  • Operating Temperature:-40°C ~ 105°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Gold
  • Mated Stacking Heights:6mm, 6.5mm
  • Ingress Protection:-
  • Features:Board Guide
  • Current Rating (Amps):1A
  • Voltage Rating:-
