D8015L56

Image is for reference, please contact us to get the real picture

Manufacturer Part
D8015L56
Manufacturer
Wickmann / Littelfuse
Description
DIODE GEN PURP 800V 9.5A TO220
Category
Discrete Semiconductor Products
Family
Diodes - Rectifiers - Single
Series
-
In Stock
0
Datasheets
-

D8015L56 Specifications

  • Series:-
  • Package:Bulk
  • Part Status:Discontinued at Digi-Key
  • Diode Type:Standard
  • Voltage - DC Reverse (Vr) (Max):800 V
  • Current - Average Rectified (Io):9.5A
  • Voltage - Forward (Vf) (Max) @ If:1.6 V @ 9.5 A
  • Speed:Standard Recovery >500ns, > 200mA (Io)
  • Reverse Recovery Time (trr):4 µs
  • Current - Reverse Leakage @ Vr:20 µA @ 800 V
  • Capacitance @ Vr, F:-
  • Mounting Type:Through Hole
  • Package / Case:TO-220-3 Isolated Tab, Formed Leads
  • Supplier Device Package:TO-220 Isolated Tab
  • Operating Temperature - Junction:-40°C ~ 125°C
