APT20F50S Specifications

• Series:POWER MOS 8™
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):500 V
• Current - Continuous Drain (Id) @ 25°C:20A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:300mOhm @ 10A, 10V
• Vgs(th) (Max) @ Id:5V @ 500µA
• Gate Charge (Qg) (Max) @ Vgs:75 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:2950 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):290W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:D3Pak
• Package / Case:TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
