TPC6012(TE85L,F,M) Specifications

• Series:U-MOSIV
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:6A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
• Rds On (Max) @ Id, Vgs:20mOhm @ 3A, 4.5V
• Vgs(th) (Max) @ Id:1.2V @ 200µA
• Gate Charge (Qg) (Max) @ Vgs:9 nC @ 5 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:630 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):700mW (Ta)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:VS-6 (2.9x2.8)
• Package / Case:SOT-23-6 Thin, TSOT-23-6
