PTCCL09H471DTE

Image is for reference, please contact us to get the real picture

Manufacturer Part
PTCCL09H471DTE
Manufacturer
Vishay BC Components/Beyshlag/Draloric
Description
PTC RESET FUSE 30V 470MA RADIAL
Category
Circuit Protection Devices
Family
PTC Resettable Fuses
Series
-
In Stock
0
Datasheets
-

PTCCL09H471DTE Specifications

  • Series:PTCCL
  • Package:Tape & Reel (TR)
  • Part Status:Obsolete
  • Type:Ceramic
  • Voltage - Max:30V
  • Current - Max:5 A
  • Current - Hold (Ih) (Max):470 mA
  • Current - Trip (It):705 mA
  • Time to Trip:-
  • Resistance - Initial (Ri) (Min):-
  • Resistance - Post Trip (R1) (Max):-
  • Resistance - 25°C (Typ):2.5 Ohms
  • Operating Temperature:-40°C ~ 85°C
  • Ratings:-
  • Mounting Type:Through Hole
  • Package / Case:Radial, Disc
  • Size / Dimension:0.335" Dia x 0.197" T (8.50mm x 5.00mm)
  • Height - Seated (Max):0.532" (13.50mm)
  • Thickness (Max):-
  • Lead Spacing:0.197" (5.00mm)
