GQ2660-9R Specifications

• Series:Melcher Q (66 ~ 132W)
• Package:Bulk
• Part Status:Active
• Type:Enclosed, Conformal Coated
• Voltage - Input (Min):21.6V
• Voltage - Input (Max):54V
• Number of Outputs:2
• Voltage - Output 1:24V
• Voltage - Output 2:24V
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):5.1A, 5.1A
• Power (Watts):132W
• Voltage - Isolation:-
• Applications:ITE (Commercial), Railway
• Efficiency:90%
• Operating Temperature:-40°C ~ 71°C
• Mounting Type:Chassis Mount
• Size / Dimension:6.73" L x 4.37" W x 0.78" H (171.0mm x 111.0mm x 19.8mm)
• Approval Agency:CE, CSA, EN, IEC, TUV, UL
• Standard Number:-
