PM3602-5-B

Image is for reference, please contact us to get the real picture

Manufacturer Part
PM3602-5-B
Manufacturer
J.W. Miller / Bourns
Description
INDUCT ARRAY 2 COIL 5UH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
0
Datasheets
-

PM3602-5-B Specifications

  • Series:PM3600
  • Package:Bulk
  • Part Status:Obsolete
  • Number of Coils:2
  • Inductance - Connected In Parallel:5 µH
  • Inductance - Connected In Series:20 µH
  • Tolerance:±20%
  • Current Rating - Parallel:2.41 A
  • Current Rating - Series:1.2 A
  • Current Saturation - Parallel:-
  • Current Saturation - Series:-
  • DC Resistance (DCR) - Parallel:23mOhm Max
  • DC Resistance (DCR) - Series:92mOhm Max
  • Shielding:Unshielded
  • Ratings:-
  • Operating Temperature:-55°C ~ 125°C
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.452" L x 0.354" W (11.48mm x 8.99mm)
  • Height:0.225" (5.72mm)
