SCX114-500

Image is for reference, please contact us to get the real picture

Manufacturer Part
SCX114-500
Manufacturer
Signal Transformer
Description
INDUCT ARRAY 2 COIL 50UH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
0
Datasheets
-

SCX114-500 Specifications

  • Series:SCX114
  • Package:Tape & Reel (TR)
  • Part Status:Obsolete
  • Number of Coils:2
  • Inductance - Connected In Parallel:50 µH
  • Inductance - Connected In Series:202.07 µH
  • Tolerance:±20%
  • Current Rating - Parallel:700 mA
  • Current Rating - Series:350 mA
  • Current Saturation - Parallel:-
  • Current Saturation - Series:-
  • DC Resistance (DCR) - Parallel:316mOhm Max
  • DC Resistance (DCR) - Series:1.263Ohm Max
  • Shielding:Unshielded
  • Ratings:-
  • Operating Temperature:-
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.461" L x 0.461" W (11.70mm x 11.70mm)
  • Height:0.217" (5.50mm)
