CTX1-2A-R

Image is for reference, please contact us to get the real picture

Manufacturer Part
CTX1-2A-R
Manufacturer
PowerStor (Eaton)
Description
INDUCT ARRAY 2 COIL 1.26UH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
0
Datasheets
-

CTX1-2A-R Specifications

  • Series:OCTA-PAC® PLUS
  • Package:Tape & Reel (TR)
  • Part Status:Obsolete
  • Number of Coils:2
  • Inductance - Connected In Parallel:1.26 µH
  • Inductance - Connected In Series:5.06 µH
  • Tolerance:±25%
  • Current Rating - Parallel:8.22 A
  • Current Rating - Series:4.11 A
  • Current Saturation - Parallel:9.38 A
  • Current Saturation - Series:4.69 A
  • DC Resistance (DCR) - Parallel:5.8mOhm Max
  • DC Resistance (DCR) - Series:23.3mOhm Max
  • Shielding:Unshielded
  • Ratings:-
  • Operating Temperature:-40°C ~ 85°C
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.450" L x 0.450" W (11.43mm x 11.43mm)
  • Height:0.235" (5.97mm)
