TLP266J(V4T7TL,E Specifications

• Series:TLP
• Package:Tape & Reel (TR)
• Part Status:Active
• Output Type:Triac
• Zero Crossing Circuit:Yes
• Number of Channels:1
• Voltage - Isolation:3750Vrms
• Voltage - Off State:600 V
• Static dV/dt (Min):200V/µs
• Current - LED Trigger (Ift) (Max):10mA
• Current - On State (It (RMS)) (Max):70 mA
• Current - Hold (Ih):600µA (Typ)
• Turn On Time:30µs
• Voltage - Forward (Vf) (Typ):1.27V
• Current - DC Forward (If) (Max):30 mA
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Surface Mount
• Package / Case:6-SOIC (0.179", 4.55mm Width), 4 Leads
• Supplier Device Package:6-SO, 4 Lead
• Approval Agency:-
