ACNT-H50L-500E Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Number of Channels:1
• Voltage - Isolation:7500Vrms
• Current Transfer Ratio (Min):31% @ 12mA
• Current Transfer Ratio (Max):80% @ 12mA
• Turn On / Turn Off Time (Typ):800ns, 1µs
• Rise / Fall Time (Typ):-
• Input Type:DC
• Output Type:Transistor
• Voltage - Output (Max):24V
• Current - Output / Channel:8mA
• Voltage - Forward (Vf) (Typ):1.45V
• Current - DC Forward (If) (Max):20 mA
• Vce Saturation (Max):-
• Operating Temperature:-40°C ~ 105°C
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.535", 13.60mm Width)
• Supplier Device Package:8-SO Stretched
