TCMT1103 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Number of Channels:1
• Voltage - Isolation:3750Vrms
• Current Transfer Ratio (Min):100% @ 10mA
• Current Transfer Ratio (Max):200% @ 10mA
• Turn On / Turn Off Time (Typ):9.5µs, 8.5µs
• Rise / Fall Time (Typ):5.5µs, 7µs
• Input Type:DC
• Output Type:Transistor
• Voltage - Output (Max):70V
• Current - Output / Channel:50mA
• Voltage - Forward (Vf) (Typ):1.35V
• Current - DC Forward (If) (Max):60 mA
• Vce Saturation (Max):300mV
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Surface Mount
• Package / Case:4-SOIC (0.173", 4.40mm Width)
• Supplier Device Package:4-SOP
