DG409LEDQ-GE3 Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:SP4T
• Multiplexer/Demultiplexer Circuit:4:1
• Number of Circuits:2
• On-State Resistance (Max):23Ohm
• Channel-to-Channel Matching (ΔRon):1Ohm
• Voltage - Supply, Single (V+):3V ~ 16V
• Voltage - Supply, Dual (V±):±3.3V ~ 8V
• Switch Time (Ton, Toff) (Max):72ns, 47ns
• -3db Bandwidth:-
• Charge Injection:-10pC
• Channel Capacitance (CS(off), CD(off)):5.5pF, 13.5pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-109dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-TSSOP (0.173", 4.40mm Width)
• Supplier Device Package:16-TSSOP
