74HCT4051D-Q100,11 Specifications

• Series:Automotive, AEC-Q100
• Package:Tape & Reel (TR)
• Part Status:Active
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:8:1
• Number of Circuits:1
• On-State Resistance (Max):120Ohm
• Channel-to-Channel Matching (ΔRon):6Ohm
• Voltage - Supply, Single (V+):4.5V ~ 5.5V
• Voltage - Supply, Dual (V±):±1V ~ 5V
• Switch Time (Ton, Toff) (Max):39ns, 32ns
• -3db Bandwidth:180MHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):3.5pF
• Current - Leakage (IS(off)) (Max):400nA
• Crosstalk:-
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SOIC (0.154", 3.90mm Width)
• Supplier Device Package:16-SO
