PCA-6MA-12-HD-3-G

Image is for reference, please contact us to get the real picture

Manufacturer Part
PCA-6MA-12-HD-3-G
Manufacturer
Adam Tech
Description
FPC/FFC CONNECTOR ZIF TYPE .5M
Category
Connectors, Interconnects
Family
FFC, FPC (Flat Flexible) Connectors
Series
-
In Stock
0
Datasheets
-

PCA-6MA-12-HD-3-G Specifications

  • Series:PCA
  • Package:Tube
  • Part Status:Obsolete
  • Flat Flex Type:FFC, FPC
  • Mounting Type:Surface Mount, Right Angle
  • Connector/Contact Type:Contacts, Top and Bottom
  • Number of Positions:12
  • Pitch:0.020" (0.50mm)
  • Termination:Solder
  • FFC, FCB Thickness:0.30mm
  • Height Above Board:0.039" (1.00mm)
  • Locking Feature:Flip Lock, Backlock
  • Cable End Type:Tapered
  • Contact Material:Copper Alloy
  • Contact Finish:Gold
  • Housing Material:Liquid Crystal Polymer (LCP)
  • Actuator Material:Liquid Crystal Polymer (LCP)
  • Features:Solder Retention, Zero Insertion Force (ZIF)
  • Voltage Rating:30V
  • Operating Temperature:-25°C ~ 85°C
  • Material Flammability Rating:UL94 V-0
