AOK15B60D

Image is for reference, please contact us to get the real picture

Manufacturer Part
AOK15B60D
Manufacturer
Alpha and Omega Semiconductor, Inc.
Description
IGBT 600V 30A 167W TO247
Category
Discrete Semiconductor Products
Family
Transistors - IGBTs - Single
Series
-
In Stock
0
Datasheets
-

AOK15B60D Specifications

  • Series:Alpha IGBT™
  • Package:Tube
  • Part Status:Active
  • IGBT Type:-
  • Voltage - Collector Emitter Breakdown (Max):600 V
  • Current - Collector (Ic) (Max):30 A
  • Current - Collector Pulsed (Icm):60 A
  • Vce(on) (Max) @ Vge, Ic:1.8V @ 15V, 15A
  • Power - Max:167 W
  • Switching Energy:510µJ (on), 110µJ (off)
  • Input Type:Standard
  • Gate Charge:25.4 nC
  • Td (on/off) @ 25°C:23ns/74ns
  • Test Condition:400V, 15A, 20Ohm, 15V
  • Reverse Recovery Time (trr):196 ns
  • Operating Temperature:-55°C ~ 175°C (TJ)
  • Mounting Type:Through Hole
  • Package / Case:TO-247-3
  • Supplier Device Package:TO-247
