DSP1-DC9V-F

Image is for reference, please contact us to get the real picture

Manufacturer Part
DSP1-DC9V-F
Manufacturer
Panasonic
Description
RELAY GENERAL PURPOSE DPST 5A 9V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
0
Datasheets
-

DSP1-DC9V-F Specifications

  • Series:DSP
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:9VDC
  • Contact Form:DPST-NO/NC (1 Form A, 1 Form B)
  • Contact Rating (Current):5 A
  • Switching Voltage:250VAC, 30VDC - Max
  • Coil Current:33.3 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Fully
  • Coil Insulation:-
  • Must Operate Voltage:7.2 VDC
  • Must Release Voltage:0.9 VDC
  • Operate Time:10 ms
  • Release Time:5 ms
  • Operating Temperature:-40°C ~ 65°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
