500DCBF-ACH Specifications

• Series:Si500D
• Package:Tube
• Part Status:Active
• Base Resonator:Crystal
• Type:XO (Standard)
• Programmable Type:Programmed by Digi-Key (Enter your frequency in Web Order Notes)
• Available Frequency Range:900 kHz ~ 200.0 MHz
• Function:Enable/Disable
• Output:LVDS
• Voltage - Supply:3.3V
• Frequency Stability:±20ppm
• Frequency Stability (Total):±250ppm
• Operating Temperature:0°C ~ 85°C
• Spread Spectrum Bandwidth:-
• Current - Supply (Max):16.5mA
• Ratings:-
• Mounting Type:Surface Mount
• Package / Case:6-SMD, No Lead
• Size / Dimension:0.157" L x 0.126" W (4.00mm x 3.20mm)
• Height - Seated (Max):0.035" (0.90mm)
