7508116313

Image is for reference, please contact us to get the real picture

Manufacturer Part
7508116313
Manufacturer
Wurth Elektronik Midcom
Description
THT OFFLINE TRANSFORMER WE-UNIT
Category
Transformers
Family
Switching Converter, SMPS Transformers
Series
-
In Stock
0
Datasheets
-

7508116313 Specifications

  • Series:MID-OLEFD
  • Package:Tray
  • Part Status:Active
  • Type:For AC/DC Converters
  • Applications:LED Drivers, AC/DC SMPS
  • Intended Chipset:-
  • Chipset Manufacturer:-
  • Voltage - Primary:120 ~ 375V
  • Voltage - Auxiliary:20V
  • Voltage - Isolation:4500Vrms
  • Inductance @ Frequency:800µH @ 10kHz
  • Frequency:68 ~ 110kHz
  • Operating Temperature:-40°C ~ 125°C
  • Mounting Type:Through Hole
  • Size / Dimension:0.846" L x 1.142" W (21.50mm x 29.00mm)
  • Height - Seated (Max):0.477" (12.12mm)
  • Footprint:0.846" L x 1.142" W (21.50mm x 29.00mm)
  • Style:-
