MF-S120

Image is for reference, please contact us to get the real picture

Manufacturer Part
MF-S120
Manufacturer
J.W. Miller / Bourns
Description
PTC RESET FUSE 15V 1.2A STRAP
Category
Circuit Protection Devices
Family
PTC Resettable Fuses
Series
-
In Stock
0
Datasheets
-

MF-S120 Specifications

  • Series:Multifuse®, MF-S
  • Package:Bulk
  • Part Status:Active
  • Type:Polymeric
  • Voltage - Max:15V
  • Current - Max:100 A
  • Current - Hold (Ih) (Max):1.2 A
  • Current - Trip (It):2.7 A
  • Time to Trip:5 s
  • Resistance - Initial (Ri) (Min):85 mOhms
  • Resistance - Post Trip (R1) (Max):220 mOhms
  • Resistance - 25°C (Typ):-
  • Operating Temperature:-40°C ~ 85°C
  • Ratings:-
  • Mounting Type:User Defined
  • Package / Case:Strap
  • Size / Dimension:0.827" L x 0.199" W (21.00mm x 5.05mm)
  • Height - Seated (Max):-
  • Thickness (Max):0.039" (1.00mm)
  • Lead Spacing:-
