15BJ22A

Image is for reference, please contact us to get the real picture

Manufacturer Part
15BJ22A
Manufacturer
PowerStor (Eaton)
Description
TVS DIODE 22V 1.5KW DO214AA
Category
Circuit Protection Devices
Family
TVS - Diodes
Series
-
In Stock
0
Datasheets
-

15BJ22A Specifications

  • Series:15BJ
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Zener
  • Unidirectional Channels:1
  • Bidirectional Channels:-
  • Voltage - Reverse Standoff (Typ):22V
  • Voltage - Breakdown (Min):24.4V
  • Voltage - Clamping (Max) @ Ipp:35.5V
  • Current - Peak Pulse (10/1000µs):42.3A
  • Power - Peak Pulse:1500W (1.5kW)
  • Power Line Protection:No
  • Applications:Telecom
  • Capacitance @ Frequency:-
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Surface Mount
  • Package / Case:DO-221AA, SMB Flat Leads
  • Supplier Device Package:SMBF
