LCM1000N-T Specifications

• Series:LCM1000 (1000W)
• Package:Bulk
• Part Status:Active
• Type:Front End
• Number of Outputs:1
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output 1:15V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):66.7A
• Power (Watts):1000W
• Applications:ITE (Commercial), Medical
• Voltage - Isolation:4 kV
• Efficiency:90%
• Operating Temperature:-40°C ~ 70°C (With Derating)
• Features:Adjustable Output, I²C™ Interface, Load Sharing, PFC, Remote On/Off, Remote Sense, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:10.00" L x 5.20" W x 2.43" H (254.0mm x 132.0mm x 61.7mm)
• Approval Agency:BMSI, CB, CCC, cCSAus, CE, TUV
• Standard Number:-
