VOF-280-48 Specifications

• Series:VOF-280 (280W)
• Package:Box
• Part Status:Active
• Type:Open Frame
• Number of Outputs:1
• Voltage - Input:90 ~ 277 VAC
• Voltage - Output 1:48V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):5.84A
• Power (Watts):168W (280W Forced Air)
• Applications:ITE (Commercial)
• Voltage - Isolation:3 kV
• Efficiency:91%
• Operating Temperature:-20°C ~ 70°C (With Derating)
• Features:Adjustable Output, PFC, Standby Output, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:5.00" L x 3.00" W x 1.38" H (127.0mm x 76.2mm x 35.0mm)
• Approval Agency:CB Scheme, CSA, EN, FCC, IEC, SIQ, TUV, UL
• Standard Number:C22.2 No. 60950-1; 60950-1; 61000-3-2; 61000-3-3; 61000-6-1; 61000-6-3; 61204-3
