TPP 450-136-M Specifications

• Series:TPP 450 (450W)
• Package:Box
• Part Status:Active
• Type:Enclosed
• Number of Outputs:1
• Voltage - Input:85 ~ 264 VAC, 120 ~ 370 VDC
• Voltage - Output 1:36V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):12.5A
• Power (Watts):450W
• Applications:ITE (Commercial), Medical
• Voltage - Isolation:4 kV
• Efficiency:93%
• Operating Temperature:-40°C ~ 80°C (With Derating)
• Features:Adjustable Output, DC Input Capable, PFC, Standby Output, Remote On/Off, Universal Input
• Mounting Type:Chassis Mount
• Size / Dimension:5.83" L x 3.15" W x 1.60" H (148.1mm x 80.0mm x 40.6mm)
• Approval Agency:CB, CE, cURus
• Standard Number:60601-1; 62368-1
