SDI12-12-UDC-ST Specifications

• Series:SDI12-UD (12W)
• Package:Box
• Part Status:Active
• Region Utilized:North America
• Form:Desktop (Class II)
• Input Type:Cord
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:12V
• Current - Output (Max):1A
• Power (Watts):12 W
• No Load Power Consumption:100mW (Max)
• Polarization:-
• Applications:ITE (Commercial)
• Efficiency:Level VI, CoC Tier 2
• Operating Temperature:0°C ~ 40°C
• Output Connector:Stripped, Tinned Wire Leads
• Cord Length:59" (1.50m)
• Input Connector:IEC 320-C8
• Size / Dimension:2.95" L x 1.50" W x 1.18" H (74.9mm x 38.1mm x 30.0mm)
• Approval Agency:CB Scheme, CSA, EN, FCC, IEC, PSE, UL
• Standard Number:C22.2 No. 60950-1; 55024; 55032 Class B; 60950-1; 61000-3-2; 61000-3-3; 62368-1
