EMMA240125-P6P-IC Specifications

• Series:EMMA (30W)
• Package:Box
• Part Status:Not For New Designs
• Region Utilized:International
• Form:Wall Mount (Class II)
• Input Type:Multi-Blade (Included)
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:24V
• Current - Output (Max):1.25A
• Power (Watts):30 W
• No Load Power Consumption:300mW (Max)
• Polarization:Positive Center
• Applications:Medical
• Efficiency:Level V
• Operating Temperature:0°C ~ 40°C
• Output Connector:Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
• Cord Length:70.9" (1.80m)
• Input Connector:Multi-Blade
• Size / Dimension:4.28" L x 2.44" W x 1.45" H (108.7mm x 62.0mm x 36.7mm)
• Approval Agency:EN, FCC, SIQ, TUV, UL
• Standard Number:55011 Class B; 60601-1; 61000-3-2; 61000-3-3; 61000-6-1; 61010-1
