SDQ25-681-R

Image is for reference, please contact us to get the real picture

Manufacturer Part
SDQ25-681-R
Manufacturer
PowerStor (Eaton)
Description
INDUCT ARRAY 2 COIL 677.4UH SMD
Category
Inductors, Coils, Chokes
Family
Arrays, Signal Transformers
Series
-
In Stock
0
Datasheets
-

SDQ25-681-R Specifications

  • Series:SDQ
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Number of Coils:2
  • Inductance - Connected In Parallel:677.4 µH
  • Inductance - Connected In Series:2.7 mH
  • Tolerance:±20%
  • Current Rating - Parallel:197 mA
  • Current Rating - Series:98 mA
  • Current Saturation - Parallel:155 mA
  • Current Saturation - Series:77 mA
  • DC Resistance (DCR) - Parallel:6.45Ohm
  • DC Resistance (DCR) - Series:25.78Ohm
  • Shielding:Shielded
  • Ratings:-
  • Operating Temperature:-40°C ~ 125°C
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Size / Dimension:0.205" L x 0.205" W (5.20mm x 5.20mm)
  • Height:0.098" (2.50mm)
