VOD223T Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Number of Channels:2
• Voltage - Isolation:4000Vrms
• Current Transfer Ratio (Min):500% @ 1mA
• Current Transfer Ratio (Max):-
• Turn On / Turn Off Time (Typ):15µs, 30µs (Min)
• Rise / Fall Time (Typ):-
• Input Type:DC
• Output Type:Darlington
• Voltage - Output (Max):30V
• Current - Output / Channel:-
• Voltage - Forward (Vf) (Typ):1.3V (Max)
• Current - DC Forward (If) (Max):30 mA
• Vce Saturation (Max):1V
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.154", 3.90mm Width)
• Supplier Device Package:8-SOIC
