W3554B0293 Specifications

• Series:-
• Package:Bag
• Part Status:Active
• RF Family/Standard:802.15.4, Bluetooth, Cellular, General ISM, Navigation, WiFi
• Frequency Group:Wide Band
• Frequency (Center/Band):829MHz, 1.5GHz, 2.2GHz, 3.55GHz, 5.45GHz
• Frequency Range:698MHz ~ 960MHz, 1.4GHz ~ 1.6GHz, 1.71GHz ~ 2.69GHz, 3.3GHz ~ 3.8GHz, 4.9GHz ~ 6GHz
• Antenna Type:PCB Trace
• Number of Bands:5
• VSWR:-
• Return Loss:-4dB, -3dB, -6dB, -5dB, -4dB
• Gain:1.9dBi, 2.5dBi, 3.2dBi, 3.3dBi, 3.5dBi
• Power - Max:5 W
• Features:Cable - 293mm
• Termination:U.FL (UMCC), IPEX MHF1
• Ingress Protection:-
• Mounting Type:Adhesive
• Height (Max):0.008" (0.20mm)
• Applications:2G, 3G, 4G, 5G, Bluetooth, GNSS, ISM, Wi-Fi, Zigbee™
