MA145.A.LBC.001 Specifications

• Series:Olympian II
• Package:Bag
• Part Status:Active
• RF Family/Standard:Cellular, Navigation, WiFi
• Frequency Group:Wide Band
• Frequency (Center/Band):657.5MHz, 752MHz, 892MHz, 1.4725GHz, 1.575GHz, 1.602GHz, 1.955GHz, 2.45GHz, 2.495GHz, 3.75GHz, 5.5GHz
• Frequency Range:617MHz ~ 698MHz, 698MHz ~ 806MHz, 824MHz ~ 960MHz, 1.427GHz ~ 1.518GHz, 1.71GHz ~ 2.2GHz, 2.4GHz ~ 2.5GHz, 2.3GHz ~ 2.69GHz, 3.3GHz ~ 4.2GHz, 5.15GHz ~ 5.85GHz
• Antenna Type:Dome
• Number of Bands:11
• VSWR:2
• Return Loss:-
• Gain:-0.2dBi, 1.3dBi, 0.4dBi, 3.6dBi, -1.98dBi, -1.67dBi, 3.8dBi, 3.5dBi, 2.7dBi, 3.1dBi, 3.6dBi
• Power - Max:10 W
• Features:Cable - 1m, LNA, Filter
• Termination:RP-SMA Male, SMA Male
• Ingress Protection:IP67
• Mounting Type:Panel Mount
• Height (Max):1.909" (48.50mm)
• Applications:3G, 4G, 5G, Beidou, Galileo, GLONASS, GNSS, GPS, HSPA, HSPA+, LTE, WCDMA, Wi-Fi
