MA285.LBICG.001 Specifications

• Series:-
• Package:Bag
• Part Status:Active
• RF Family/Standard:Cellular, Navigation, WiFi
• Frequency Group:Wide Band
• Frequency (Center/Band):750.5MHz, 869MHz, 920MHz, 1.561GHz, 1.575GHz, 1.602GHz, 1.795GHz, 1.92GHz, 2.045GHz, 2.4GHz, 2.495GHz
• Frequency Range:698MHz ~ 803MHz, 824MHz ~ 894MHz, 880MHz ~ 960MHz, 1.559GHz ~ 1.563GHz, 1.574GHz ~ 1.576GHz, 1.597GHz ~ 1.607GHz, 1.71GHz ~ 1.88GHz, 1.85GHz ~ 1.99GHz, 1.92GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz, 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.85GHz
• Antenna Type:Module
• Number of Bands:12
• VSWR:-
• Return Loss:-6dB, -10dB
• Gain:1.99dBi, 2.34dBi, 1.98dBi, 2.3dBi, 3.15dBi, 3.63dBi, 4.11dBi, 2.85dBi, -3.01dBi, -2.07dBi
• Power - Max:-
• Features:Cable - 2m, LNA, Filter
• Termination:RP-SMA Male (1), SMA Male (2)
• Ingress Protection:IP67
• Mounting Type:Adhesive
• Height (Max):0.512" (13.00mm)
• Applications:Beidou, DCS, Galileo, GLONASS, GNSS, GPS, GSM, LTE, PCS, Wi-Fi
