DG9408EDN-T1-GE4 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:8:1
• Number of Circuits:1
• On-State Resistance (Max):7Ohm
• Channel-to-Channel Matching (ΔRon):3.6Ohm (Max)
• Voltage - Supply, Single (V+):2.7V ~ 12V
• Voltage - Supply, Dual (V±):±3V ~ 6V
• Switch Time (Ton, Toff) (Max):70ns, 44ns
• -3db Bandwidth:-
• Charge Injection:29pC
• Channel Capacitance (CS(off), CD(off)):21pF, 211pF
• Current - Leakage (IS(off)) (Max):2nA
• Crosstalk:-85dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-VQFN Exposed Pad
• Supplier Device Package:16-QFN (4x4)
