MAX4051AEEE+ Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:8:1
• Number of Circuits:1
• On-State Resistance (Max):100Ohm
• Channel-to-Channel Matching (ΔRon):6Ohm (Max)
• Voltage - Supply, Single (V+):2V ~ 16V
• Voltage - Supply, Dual (V±):±2.7V ~ 8V
• Switch Time (Ton, Toff) (Max):175ns, 150ns
• -3db Bandwidth:-
• Charge Injection:2pC
• Channel Capacitance (CS(off), CD(off)):2pF, 2pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-90dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SSOP (0.154", 3.90mm Width)
• Supplier Device Package:16-QSOP
