MAX4732EUA+ Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):25Ohm
• Channel-to-Channel Matching (ΔRon):200mOhm
• Voltage - Supply, Single (V+):2V ~ 11V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):85ns, 45ns
• -3db Bandwidth:300MHz
• Charge Injection:7.5pC
• Channel Capacitance (CS(off), CD(off)):20pF, 20pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-108dB @ 1MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
• Supplier Device Package:8-uMAX
