MAX326CEE+ Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):3.5kOhm
• Channel-to-Channel Matching (ΔRon):175Ohm
• Voltage - Supply, Single (V+):10V ~ 30V
• Voltage - Supply, Dual (V±):±5V ~ 18V
• Switch Time (Ton, Toff) (Max):1µs, 500ns
• -3db Bandwidth:-
• Charge Injection:2pC
• Channel Capacitance (CS(off), CD(off)):1.7pF, 1.7pF
• Current - Leakage (IS(off)) (Max):10pA
• Crosstalk:-90dB @ 100kHz
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SSOP (0.154", 3.90mm Width)
• Supplier Device Package:16-QSOP
