MAX4657EUA+ Specifications

• Series:-
• Package:Tube
• Part Status:Active
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:1
• On-State Resistance (Max):10Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):9V ~ 40V
• Voltage - Supply, Dual (V±):±4.5V ~ 20V
• Switch Time (Ton, Toff) (Max):200ns, 100ns
• -3db Bandwidth:210MHz
• Charge Injection:23pC
• Channel Capacitance (CS(off), CD(off)):25pF, 25pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
• Supplier Device Package:8-uMAX
