MAX4582CEE+T Specifications

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Switch Circuit:SP4T
• Multiplexer/Demultiplexer Circuit:4:1
• Number of Circuits:2
• On-State Resistance (Max):80Ohm
• Channel-to-Channel Matching (ΔRon):1Ohm
• Voltage - Supply, Single (V+):2V ~ 12V
• Voltage - Supply, Dual (V±):±2V ~ 6V
• Switch Time (Ton, Toff) (Max):200ns, 100ns
• -3db Bandwidth:-
• Charge Injection:0.5pC
• Channel Capacitance (CS(off), CD(off)):4pF, 10pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-96dB @ 1MHz
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SSOP (0.154", 3.90mm Width)
• Supplier Device Package:16-QSOP
