ADG884BCPZ-REEL7 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):370mOhm
• Channel-to-Channel Matching (ΔRon):10mOhm
• Voltage - Supply, Single (V+):1.8V ~ 5.5V
• Voltage - Supply, Dual (V±):-
• Switch Time (Ton, Toff) (Max):50ns, 20ns
• -3db Bandwidth:18MHz
• Charge Injection:125pC
• Channel Capacitance (CS(off), CD(off)):103pF
• Current - Leakage (IS(off)) (Max):200pA (Typ)
• Crosstalk:-120dB @ 100kHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:10-VFDFN Exposed Pad, CSP
• Supplier Device Package:10-LFCSP-WD (3x3)
