74HCT4316D,118 Specifications

• Series:-
• Package:Bulk
• Part Status:Active
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:4
• On-State Resistance (Max):135Ohm
• Channel-to-Channel Matching (ΔRon):6Ohm
• Voltage - Supply, Single (V+):4.5V ~ 5.5V
• Voltage - Supply, Dual (V±):±1V ~ 5V
• Switch Time (Ton, Toff) (Max):42ns, 34ns
• -3db Bandwidth:160MHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):3.5pF
• Current - Leakage (IS(off)) (Max):100nA
• Crosstalk:-60dB @ 1MHz
• Operating Temperature:-40°C ~ 125°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SOIC (0.154", 3.90mm Width)
• Supplier Device Package:16-SO
