AP1154ADL33 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• Output Configuration:Positive
• Output Type:Fixed
• Number of Regulators:1
• Voltage - Input (Max):14V
• Voltage - Output (Min/Fixed):3.3V
• Voltage - Output (Max):-
• Voltage Dropout (Max):0.67V @ 1A
• Current - Output:1A
• Current - Quiescent (Iq):624 µA
• Current - Supply (Max):1.8 mA
• PSRR:80dB (1kHz)
• Control Features:Current Limit, Enable
• Protection Features:Over Current, Over Temperature, Reverse Polarity, Short Circuit
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-SOIC (0.173", 4.40mm Width) Exposed Pad
• Supplier Device Package:8-HSOP
