LM2940SX-10/NOPB Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Output Configuration:Positive
• Output Type:Fixed
• Number of Regulators:1
• Voltage - Input (Max):26V
• Voltage - Output (Min/Fixed):10V
• Voltage - Output (Max):-
• Voltage Dropout (Max):1V @ 1A
• Current - Output:1A
• Current - Quiescent (Iq):10 mA
• Current - Supply (Max):15 mA
• PSRR:63dB (120Hz)
• Control Features:-
• Protection Features:Over Current, Over Temperature, Reverse Polarity, Short Circuit
• Operating Temperature:-40°C ~ 125°C
• Mounting Type:Surface Mount
• Package / Case:TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
• Supplier Device Package:DDPAK/TO-263-3
